75 Mould Automatic Wafer Line Equipment

The 75 mould automatic wafer line equipment is mainly adopted by large sized company or transnational enterprise. These companies are very large, and the most important factors are whether the production capacity meets the need, and if our machine can manufacture wafer with custom made shape. Then, a lot of attention is paid to the technical parameters. They must confirm that the output is satisfied, and the production cost is also taken into consideration. This product has the largest production capacity among the 7 models, and it is recommended if the output is quite large.

Suitable Users
1. Medium sized factory
2. Large sized company
3. Transnational enterprise

Important Factors
This wafer line equipment asks for a plant whose L×W×H is 60m×8m×(≥3.5m). Meanwhile, the cost, gas source and production capacity are also very important.

1. Production capacity: 8.2 tons/24 hours
2. Total power: 50.00kW and the power supply is 380V/50Hz. For electrical heating, the total power is 300kW.
3. Rate of finished product: ≥98%
4. Fuel gas pressure: 0.25-3.5kg/cm2
5. Gas consumption: 42kg/hour for liquefied gas, and 54m3/hour for natural gas.
6. Combustion value: 8.4 for liquefied petroleum gas, and 4.7 for natural gas.
7. Compressed air consumption and pressure: 0.9m3/min, 0.8Mpa
8. Baking plate size: 500mm×350mm
9. Effective cutting size of wafer sheet: 485mm×340mm
10. Baking time: 90 seconds
11. Overall dimensions (L×W×H): 35.10m×3.5m×2.4m
12. Overall weight: About 26 tons
13. Number of operators: 4 (packing staff is not included)
14. Testing staff: 1-2 people
15. Testing time: 20 days
16. Shipping: 3×40′ HQ container
17. Delivery time: Within 180 days after the advance payment is received.
18. Packing: Standard export packing

Composition Facilities
Featured Machine Supporting Machine
Name Baking oven Wafer sheet receiver Wafer cooling tower Sheet picking machine Cream spreading machine Wafer vertical cooling cabinet Wafer sheet conveyor Wafer cutter and laminator Batter mixer Automatic cream delivering machine Wafer smashing machine
Qty. 1 1 1 1 1 1 1 1 1 1 1

As a China-based 75 mould automatic wafer line equipment manufacturer and supplier, we also provide 65 mould fully automatic wafer production line, soft wafer biscuit production line, chocolate hazelnut ball production line, and more.
